Overview of 2jmx diaphragm metering pump
娱乐中心Adjustable metering range: 0-240l / h (120L / h for larger single head)
Large pressure range: 0-0.4mpa
Driving mode: motor driven
Control mode: manual and automatic control (can receive 4-20mA signal to adjust the flow)
1. Cast aluminum shell, high heat dissipation performance, light overall weight, suitable for all kinds of acid and alkali solution, non-toxic and tasteless.
2. Double cam mechanism, superior performance ratio, double head dosing.
娱乐中心3. Contact medium pump head is made of PVC, PTFE and stainless steel.
娱乐中心4. It is widely used in water treatment industry with low pressure requirements due to its high cost performance.
娱乐中心5. When the pump is running or stopped, the flow can also be adjusted at will, and the output can be quantified.
娱乐中心6. The diaphragm is pressed by multi-layer composite structure. The first layer is super tough Teflon acid resistant film, the second layer is EPDM elastic rubber, the third layer is 3.mm thick SUS304 to support the iron core, the fourth layer is reinforced by reinforced nylon fiber, and the fifth layer is fully covered with EPDM elastic rubber, which can effectively improve the service life of the diaphragm.
2jmx mechanical diaphragm metering pump is widely used in petrochemical, chemical, electric power, metallurgy, mining, shipbuilding, light industry, agriculture, national defense and other industries
