Product overview
娱乐中心CHL, chlk and chlf (T) light horizontal multistage centrifugal pumps are equipped with repair free mechanical seals. The flow passage parts of the pump are made of stainless steel (304 or 316), with low noise, light corrosion resistance, beautiful appearance, small volume, light weight and long service life.
Scope of application
娱乐中心CHL, chlk and chlf (T) pumps are mainly used for household central air conditioning circulation and industrial liquid transmission. Such as demineralization water, soft water, purification system, light oil circulation and pressurization.
娱乐中心1) Small central air conditioning cycle
娱乐中心2) Cooling system
娱乐中心3) Industrial cleaning
4) Water treatment (water purification)
5) Aquaculture
娱乐中心6) Fertilization / metering system
娱乐中心7) Environmental applications
娱乐中心Working conditions
A liquid that is thin, clean, non condensing, non explosive, and does not contain solid particles or fibers.
Liquid temperature:
Normal temperature type - 15 ℃ to + 70 ℃
Hot water type + 70 ℃ to + 110 ℃
Ambient temperature + 40 ° C
Operating pressure: 10 bar
Medium pH: 4 ~ 9
electric machinery
娱乐中心The motor is totally enclosed, air-cooled two pole motor
娱乐中心Protection grade: IP55
娱乐中心Insulation class: F standard voltage,
50Hz：1×220-240V 3×220-240V 380-415Vv
娱乐中心CHL, chlk and chlf (T) pumps are mainly used for household central air conditioning circulation and industrial liquid transmission.
Such as demineralization water, soft water, purification system, light oil circulation and pressurization.
娱乐中心1) Small central air conditioning cycle
2) Cooling system
3) Industrial cleaning
娱乐中心4) Water treatment (water purification)
娱乐中心5) Aquaculture
6) Fertilization / metering system
7) Environmental applications
娱乐中心A liquid that is thin, clean, non condensing, non explosive, and does not contain solid particles or fibers.
Liquid temperature: normal temperature type - 15 ℃ to + 70 ℃ hot water type + 70 ℃ to + 200 ℃
娱乐中心Ambient temperature + 40 ° C
Operating pressure: 10 bar
Medium pH: 4 ~ 9
